A 100% ATEX PRODUCT FOR GAS AND DUST WITH 50,000-COUNT TRMS

Measurements in complete safety in difficult and explosive areas

This ATEX-certified instrument is designed for use in dangerous or explosive "gas" or "dust" environments, in compliance with the EN 50014, 50020 and 50281-1-1 standards.

It also complies with the following specifications:

- ATEX 94/9/CE directive
EN/IEC 60079-0  EN/IEC 60079-11
EN/IEC 61241-11  EN/IEC 61241-0
EN/IEC 61010-1  600 V CAT III

It is certified LCIE 02 ATEX 6005 X and, as per the "old regulations", EEx ib IIc T5/ EEx ib I according to:
- CE inspection certificate number
LCIE 02 ATEX 6005 X and additional clauses
LCIE 02 ATEX 6005X / 01, 02, 03

It is equipped with a 500mA fuse and the patented SECURIX system to prevent accidental disconnection of the leads. It is delivered in a carrying bag, accompanied by some of its accessories.

* Bargraph; zoom or central zero
* VDC from 0.5 to 60 V
* AC and AC+DC voltage from 0.5 to 60 V
* DC bandwidth 50 kHz
* AC and AC+DC current from 500 μA to 500 mA
* Resistance from 500 Ω to 50 MΩ
* MIN, MAX and Average
* Frequency, capacitance, temperature, dB, resistive power, duty cycle, pulse
  width/chronometer, event counter
* Continuity test, diode test
* RS232 optical interface available as an option for transferring the measurements onto a PC
  or printer.
