ITL-M-17701 Low Temperature Fixed Point Furnace is designed specifically to realize and maintain the freeze plateaux of Isotech Indium, Tin and Zinc Fixed Point Cells, for calibration of thermometers on the International Temperature Scale of 1990.

The Low Temperature Furnace is a single-zone furnace.

The recommended procedure for establishing a freeze plateau requires operator attention until the plateau is realized. Following that, the Model 17701 Furnace will maintain the indium or the tin plateau, essentially automatically, for a period of 10 to 12 hours and the zinc plateau for 6 to 8 hours.

Fixed Points :
* Indium 156.5985°C

* Tin 231.928°C

* Zinc 419.527°C

* For plateaux of 6 to 12 hours

Two entirely independent over-temperature safety devices are included. A dedicated (on-off) over-temperature control circuit provides active safety. A fusible link in the main power circuit provides passive safety.
