E clamps
.jpg)
.jpg "2(441).jpg")
For measurement from 5mA to 150A
The E series is designed to measure AC and DC current using Hall-effect technology. The current measured ranges from a few milliamperes to over 100A.
* The clamps are long and narrow in shape for measuring cable cores or in confined spaces
* Their low phase displacement ensures excellent power measurement performance
* Voltage output (mV)
* Measurement of AC+DC signals for true RMS measurements
* Can be connected to multimeters, recorders, acquisition units, oscilloscopes
(model E3N - clamp with BNC connector), etc.
.jpg "3(13).jpg")
