Detection and location of electrical faults
The B102 clamp is designed for measuring leakage current diverted towards the earth. It enables the fault to be located or anticipated without disconnecting the equipment linked.
It is specially designed to detect low fault currents on power circuits.
* differential or leakage current, starting from 500μA
* current up to a maximum of 400A
* 2 measurement ranges: 1mV/mA or 1 mV/A
* utilisation on single or multi-phase systems, with phased or unphased currents and on
balanced or unbalanced circuits
* jaw opening - 100mm
* measurement of fault current on 3-phase, 3-wire circuits without a neutral using an artificial
neutral device
