CA8220
NEW!
POWER ANALYSER AND MOTOR DIAGNOSTIC TOOLS
Firmly geared towards electrotechnics and the verification of rotating machinery, the C.A 8220 is intended for companies' testing and maintenance teams.
Equipped with a segmented liquid crystal display, compact and shock-resistant, its ergonomic man-machine interface makes it simple and pleasant to use because it is intuitive.
Like the C.A 8230, the C.A 8220 can be used to obtain a snapshot of the main characteristics of a single-phase or balanced three-phase grid.
It also measures all the characteristics needed to check rotating machinery.
It allows accurate measurements from a few millamperes to several kiloamperes, as required, by means of a wide range of sensors.
Rotation speed: predictive maintenance requires regular verification of the rotation speed of rotating machinery. The C.A 8220, an all-in-one instrument, fulfils this need simply and efficiently.
Temperature: the motors and rotating machinery currently used are equipped with temperature probes which are easily accessible on a terminal block. This makes it possible to measure the motor's internal temperature directly by simply connecting the C.A 8220 to this terminal block.
The C.A 8220 is supplied with the PAT (Power Analyser Transfer) software for processing the measurements on a PC (display, analysis, etc).
This software is available free of charge for download from our internet site (www.chauvin-arnoux.com/SUNSUPPORT/support).
