F11N
.jpg)
Efficient electrical diagnosis - at long last!
Two instruments in one: The F11N combines the advantages of an ammeter clamp with the function possibilities of a multimeter.
For measuring intensity on U1000RO2V-1x6302and HO7RNF-1x3002cables or on 2 bars 50mmx5mm.
* AC intensity: 400 and 700A (2 cal.)
* accuracy 2%+/-0.5A on cal. 400A, 2% on cal. 700A
* AC & DC voltage: 400 and 600V (2 cal.)
* accuracy 0.5% for DC, 1% for AC
* bandwidth: 45-450Hz
* average value
* impedance: 1MΩ
* resistance: 400Ω to 4kΩ (2 cal.), acc. 1%
* Audio continuity test: R < 40Ω
* memory and max value functions
* clamping: cable ø42mm, 2 50 x 5mm bars
* electrical safety: IEC 1010 600V Cat III-2
* dimensions: 254 x 97 x 46mm. Weight: 600g
