TRMS 최고 수준의 산업용 클램프
 단상 및 평형 삼상 전력 측정

NEW

A fully automatic pocket RMS & DC clamp

The F09 is a new pocket-size, all-purpose, small-diameter clamp, operated with one hand.
 Ideal for U1000RO2V-1X185 2and H07RNF-1x70 cables2 or 20mmx5mm bars, it is a professional measurement tool (600V Cat.III). Fully automatic, TRMS AC+DC, the F09 is a must for all your measurements

* clamping: ø26mm
* AC and DC intensity: 0.20 to 40/400A (600A peak)
* AC and DC voltage: 0.20 to 40/400/600V (900V peak)
* phase rotation (2-wire)
* inrush current
* power (single & three phased): 5W to 240kW ; 5 to 240kvar ; 5 to 240kVA
* power factor
* Hz frequency
* auto AC/DC - Hold
* automatic DC zero
* resistance: 0 to 40kΩ
* continuity / buzzer
* diode test
* min/max/peak
* automatic lead compensation
* backlit display
* range overrun buzzer
* battery charge level
* automatic stop
* dangerous voltage signal
* dimensions: 70 x 193 x 37mm - weight: 260g
