F13N
.jpg)
The 700A RMS multimeter clamp - specially for general low-voltage switchboards
Specially designed for equipment with non-linear loads, the F13N multimeter clamp gives an RMS measurement whether the current is deformed or sinusoidal.
* AC intensity: 400 and 700A (2 cal.)
* accuracy: 2%+/-0.5A
* AC & DC voltage: 400 and 600V (2 cal.)
* accuracy: 0.5%+/-2ct for DC, over 1%+/-10ct for AC
* impedance 1MΩ
* bandwidth: 45Hz-450Hz
* RMS
* resistance: 400Ω to 4kΩ (2 cal.), accuracy 1%+/-3ct
* audible continuity test: R < 40Ω
* memory and max value functions
* frequency 1Hz to 4kHz, acc. 0.1%+/-1ct
* 4,000-count display with large, 12.5mm digits
* clamping: cable ø42mm, 2 50 x 5mm bars
* electrical safety: IEC 1010 -600V Cat III
* dimensions: 254 x 97 x 46mm. Weight: 600g
